CO-8-35 Consolidation Complete Drawing Set
This is the complete set of drawings needed to build the Allen Consolidation 2-8-0. A sample sheet thumbnail and a sample drawing detail of the crosshead is shown here. The drawings sheets range in size from 24" X 36" to 30" X 60" for some of the larger erection drawings depending on the locomotive. See below for a complete list of sheets included.
This is the complete set of drawings needed to build the 2-8-0 Consolidation. The drawings sheets range in size from 24" X 46" to 30" X 60" for some of the larger erection drawings depending on the locomotive. The complete list of sheets for the Consolidation is as follows. Note that not all sheets are in continuous numerical order as some sheets are shared between locomotives and retain their numbering.
|
1 Erection side |
18 lead truck, coupler 19 swing link lead truck 20 lead truck 21 smokebox – stack 22 smokebox door 23 misc. details 24 cab 25 piping details 26 ball bearing truck 27 tender frame detail 28 tender frame 29 tender erection 30 misc. details 31 throttle and steam line 32 boiler 33 boiler 34 boiler erection 35 ash pan |
